Vertical Slitting and Rewinding Machine
Servo motor driving system,PLC control.
Subsection tension control.
Hydraulic automatic loading
Features:
● Compact structure ,easy operation.
● Servo motor driving system,PLC control.
● Subsection tension control.
● Hydraulic automatic loading
● Rewinding platform
● Laser paper core positioning.
● Multi slitting type.
● Rewinding differentia shaft.
Technical parameters
Model | XY-700 | XY-1100 | XY-1300 |
Max.width of mather roll | 700mm | 1100mm | 1300mm |
Max.diameter of mother roll | 600mm | 600mm | 600mm |
Width of roll material cutting | 30-600mm | 30-1000mm | 30-1200mm |
Speed | 5-200m/min | 5-200m/min | 5-200m/min |
Deviation rectifying error | ±0.5mm | ±0.5mm | ±0.5mm |
Total power | 2.7kw | 3.5kw | 3.5kw |
Machine weight | 1200kg | 1500kg | 1800kg |
Machine size | 2.0x1.1x1.4m | 2.3x1.1x1.4m | 2.6x1.1x1.4m |
※Correct specifications depend on the actual model. All specifications are subject to change without prior notice.
Machine photo
